1638 – 2500 KVA XQ2000 Diesel Generator Set
MAXIMUM RATING
250 ekW
MINIMUM RATING
225 ekW
EMISSIONS/FUEL STRATEGY
Low Fuel consumption
250 ekW
MINIMUM RATING
225 ekW
EMISSIONS/FUEL STRATEGY
Low Fuel consumption
Spec-Sheet-CAT-XQ2000
Spec-Sheet-CAT-XQ2000-3516B
Spec-Sheet-CAT-XQ2000-3516COVERVIEW
2000 KW Portable Generator Set
The XQ2000 portable generator set offers a reliable power source of 2000 KW at 60 Hz. Field-ready and delivered in a package ready to be connected to power and fuel lines. This portable generator set was designed in an ISO 9001:2000 compliant facility and is EPA TIER 2 and CARB certified for non-road mobile applications.
FEATURES AT A GLANCE
| Precise control, block loading, and constant voltage in the normal operating range |
| Fuel system operates on an array of fuels |
| Sound attenuated design to minimize noise pollution |
| Easy transportation and set-up at site |
Your one-stop-shop for power equipment solutions.
When you work with React Power Solutions, we have the unique ability to offer custom solutions to the challenges you face on your worksite. Based in Houston, TX, we have everything you need to thrive in challenging work sites.
GENERATOR SET SPECIFICATIONS
| Minimum Rating | 1825 kW |
| Maximum Rating | 2000 kW |
| Frequency | 50- 60 Hz |
| Voltages | 277 to 480 Volts |
| Duty Cycle | Standby, Prime |
ENGINE SPECIFICATIONS
| Engine Model | 3516B, 3516C |
| Bore | 6.7 in |
| Stroke | 7.5 in |
| Displacement | 4,210 in³ |
| Compression Ratio | 15:1 |
| Governor type | Caterpillar ADEM™ A3 Control System |
| Aspiration | ATAAC |
| Fuel System | EUI |
DIMENSIONS
| Length – Maximum | 480 in |
| Width – Maximum | 96 in |
| Height – Maximum | 168 in |
CAT XQ2000 Diesel Generator
To get more information on the CAT XQ2000 Diesel Generator, please send us a quick message and one of our specialists will contact you right away.
